ÖkoFlussPlan: Real Lab - Sustainable community centre in Kyrgyzstan

Construction progress of the community centre (from left to right): Excavation, installation of the external wall insulation made of reed and plastering

The Institute of new Energy Systems (InES) at Ingolstadt University of Applied Sciences (THI) is responsible for work package 5 (renewable energies) in the ÖkoFlussPlan project. The main objective of this work package is to find feasible solutions for the integration of renewable energies in rural Kyrgyzstan. In addition to the planned scope of the ÖkoFlussPlan project, the of a community house, called "Real Lab", was constructed to demonstrate the use of sustainable energy solutions.

Heating scheme

The heating system of the Ak-Tal community centre consists of two generation plants. A solid fuel stove and a solar thermal system generate heat that can be temporarily stored in the storage tank. When needed, heat can then be distributed to the building via the radiators with the help of an intelligent control system. The following diagram shows live data of the energy system.

For display problems please klick HERE.

Live view

Welcome to the live webcam of the "Real Lab" community centre, a key component of our research project. This is a building of approximately 100 m², which was built using traditional construction methods. In addition, the house was equipped with insulation made of reeds and a solar thermal system, which ensures the supply of the building with space heating and hot water. This facility serves as a central meeting point in the community.
For display problems please klick HERE.
